Fire-Rated Rolling Service Doors 630/631/634/635
Our FIREKING® Rolling Fire Door Collection, Fire-Rated Rolling Service Doors 630/631/634/635, offers fire protection, innovative design, and optimized performance. Additional benefits, including thermal efficiency, climate control, and sound control, are available with our FireKing® Insulated Fire Door (Model 635), which provides an R-value of 4.5, smoke and flame index of 5, and STC of 21.
Innovative Design & Optimal Performance
FireKing® Fire Doors are equipped with an innovative floor reset system, which allows them to be easily dropped tested and mechanically reset at any time without special tools.
Ideal Applications Include
Parking Garage
Warehouse Solutions
Public Facilities
Fire-Rated Rolling Service Doors 630/631/634/635 Overview
Additional safety and protection features include Fire Sentinel® time-delay release device, FireLite® vision lites, smoke detectors, horns, and strobes.
FireKing® Model 635
The Model 635 insulated fire door has UL (FM optional) labels for 1-1/2, 3, 4, and oversized doors.
- Energy efficient: Insulation R-value of 4.5
- Sound Transmission Class 21: Ideal for applications that require sound control
FireKing® Model 630
Max Width: 41’2” (12548 mm)
Max Height: 25’4” (7722 mm)
Curtain
- Painted galvanized / stainless steel
- Slat profile available in curved or flat.
- Standard finish available in gray, tan, white, or brown
FireKing® Model 631
Max Width: 14′ (4267 mm)
Max Height: 12′ (3658 mm)
Curtain Material:
- Painted galvanized
- Standard baked-on paint finish available in gray, tan, white, or brown
FireKing® Model 634
Max Width: 41’2” (12548 mm)
Max Height: 25’4” (7722 mm)
Curtain Material:
- Painted galvanized / stainless steel
- Slat profile available in curved or flat.
- Standard finish available in gray, tan, white or brown
FireKing® Model 635
Max Width: 24’0″ (7315 mm)
Max Height: 24’0″ (7315 mm)
Curtain Material:
- Galvanized or stainless steel in a variety of gauges
- Flat slat profile
- Standard finish available in gray, tan, white or brown
Guides:
- Three structural steel or stainless steel angles.
- Guides also include a locking bar or wind bar PowderGuard® Weathered finish with black powder coat.
Labels available for masonry or non-masonry applications:
- UL/ULC 1-1/2 hr (FM is optional),
- UL/ULC 3 hr (FM is optional),
- UL 4 hr,
- UL oversized door (FM is optional)
- Model 731 – Underwriters Laboratories (UL & ULC)
Mechanical auto resettable hoist (non-motorized): Enables easy drop test and reset of fire door in seconds
Fusible link for added safety: Separates at 165°F (74°C) to automatically close the door in case of fire
Viscous governor technology: Controls the rate of door descent during a fire while reducing noise and vibration for quieter door operation
Innovative planetary gear design Ensures years of reliable service and drop-out performance.
Fire doors comply with
- National Fire Protection Association (NFPA-80)
- Underwriters Laboratories (UL & ULC)
- New York City (MEA)
- State of California (CSFM)
Warranty
- 24 month limited warranty on door 3 year/20,000 cycle limited on door operator system (when purchased together)
- Operation: chain hoist, crank, and electric motor (RHX® FK, RHX® or RSX®)
- Fire Sentinel® time-delay release device
- FireLite® vision lites
- UL listed brush-type smoke seals
- Flame baffle system (required for optional FM label)
- Smoke detectors
- Horns and horns with strobes
- Cylinder locking bottom bar with mortise cylinder
- Wind load (FBC, TDI, Miami-Dade)
- PowderGuard® Premium powder coat finish options are available in approximately 200 colors and custom matching to specification.
- PowderGuard® Zinc and PowderGuard® Weathered finishes
Exterior Color Options
Model 592 Colors
White Tan Gray Brown
Powder Coat Color Options
PowderGuard® Premium powder coat options are available in approximately 200 colors and custom matching to specification.
