High Speed Interior Fabric Door Model 992
RapidFlex® Model 992 is a strutted, heavy-duty interior/exterior high speed fabric door with independently tested wind load of up to 4.0 psf. Its industry-leading standard safety features include a reversing edge, two sets of infrared obstruction detection sensors, and a door stop device.
Engineered for high cycles
- Springless design requires minimal interruption for maintenance
- Direct-mounted gear drive minimizes wear and tear
- Variable frequency drive eliminates sudden jolts from door start/stop
- Patent-pending breakaway system design with impact detection and push button self-repair
Ideal Applications Include
Manufacturing Facilities
Food & Beerage
Cold Storage
Warehouse Facilities
High Speed Interior Fabric Door Model 992 Overview
Strut design:
- Allows for quick section replacement
- Reducing curtain deflection under pressure
Designed for use in both interior and exterior applications
- Choose from standard interior or optional exterior curtain material
Optional programmable LED lighting system
Low maintenance
- Breakaway design with side impact detection and
- Push button self-repair; plug and play wiring
The standard hood blocks moisture and debris from impeding door operation.
Construction – Product Specifications
Standard Max Width 16”
Standard Max Height 15′
Opening Speed: Up to 65″ per second
Break-away Self-reset: Designed to break away from the side guides to minimize damage and simply reset and self-repair after the event
Wind Strut: 1″ strut standard
Interior Application Curtain Material 2 layers of PVC coated polyester with 1 layer of polyester weave
Operation: Direct drive motor and gearbox system with a door stop device
Control: Variable frequency drive, NEMA 4X cULus listed, Onboard self-diagnostic and service reminder, Built-in padlockable field disconnect
Obstruction Safety Detection: Infrared sensors mounted in-plane to the door curtain at 16″ and 50″ – 54″ from the floor
Reversing Safety Edge: Wireless reversing edge
Electrical Availability: 230V AC 3PH; 460V AC 3PH; 575V AC 3PH† (†requires stand-alone mounted transformer)
†Requires stand-alone mounted transformer
Wind Load*: Up to 4.0 psf
**Single phase available up to 10’ doors.
* Pressure/wind resistance value is the ultimate pressure tested at a door width of 16′.
Warranty: 5-year limited on drive motor and gearbox; 1-year limited on all other available components
Enhancements
Exterior/Interior application curtain material upgrade
3 layers of PVC-coated polyester with 2 layers of polyester weave
Actuation options
Push button, key switch, pull switch, loop detector, motion detector, treadle switch, radio control. Wireless options available
Signaling device options
Red/green LED warning light, horn/strobe combination, rotating warning light
Light Curtain
Front or rear mounted; available in 3′ or 6′ models
Programmable LED lighting system
3′ tall light bar with red, yellow, green lighting
Sloped hood and non-drive end cover
Protection from debris and moisture
20″ high vision panels
Spaced evenly across the width of the door
Food and beverage applications
An FDA-compliant fabric is available
Colors
Red Blue Gray Black
Exterior Colors
Red Blue Gray Orange
FDA Compliant Applications
Royal Blue White
Bottom Bar & Guide
The standard color for guides, brackets, and the bottom bar is yellow.
Safety Yellow
RAL Powder Coat
197 optional RAL powder coat color options are available. The actual door color may vary from the digital representation shown here. Color samples are available; please get in touch with us.
Overhead Door™ High Performance Collection
With robust safety features and a pressure-resistant design, these high performance doors will keep your facility running securely, efficiently, and environmentally controlled.
