EverServe® Rolling Service Door 610s/620s/625s
This heavy duty Stormtite™ springless service door is best suited for exterior applications exposed to harsh weather. EverServe® Rolling Service Door 610s/620s/625s provides security, reliability, ease of serviceability, and advanced weather protection. The perimeter seals included in this design help protect against extreme weather conditions.
Low Maintenance & Ease of Serviceability
EverServe® Model 610S is well suited for applications that require the security and performance of a rolling service door with the added benefits of increased cycle life, reliability, and ease of serviceability. The fenestration option allows air circulation and visibility, making it an ideal solution for facility managers seeking to replace parking garage grilles.
EverServe® Model 620S is best suited for exterior applications exposed to harsh weather. It provides security, reliability, ease of serviceability, and advanced weather protection. The perimeter seals included in this design help protect against extreme weather conditions.
EverServe® Model 625S delivers security, reliability, and ease of service and is best suited for applications that require protection against weather extremes. The insulated slats provide climate control and sound reduction, while perimeter seals provide additional protection from weather.
Ideal Applications Include
Manufacturing & Warehouse Solutions
Food & Beverage
Healthcare
Public Facilities
Government Facilities
Automotive & Parking Garages
EverServe® Rolling Service Door 610s/620s/625s Overview
The EverServe® door system provides customers with high cycle performance, improved security, and durability while delivering a reliable system, minimizing downtime with ease of serviceability. The springless design builds on the proven construction of the Overhead Door™ brand rolling steel line, adding significant enhancements to provide 25 times the standard service door cycle life.
Key features of the springless system include:
- Springless operation eliminates the need for a counterbalance
- Performance and functionality with minimum maintenance requirements
- 500,000 cycle life
- Universal components for ease of maintenance
- Floor-level controller for ease of access control and maintenance
- Direct drive integrated gear/motor/brake assembly; built-in braking mechanism provides additional peace of mind against uncontrolled curtain travel.
- A variety of insulation, weather seal, and airflow options are available to satisfy applications in a wide range of environmental conditions
- Field-installable accessories such as radio controls or motion detectors to match a wide range of application requirements
- 36 month limited warranty on the door system.
EverServe® Model 610s
Max Width: up to 30′ (9246 mm) depending on gauge and slat type
Max Height: up to 20′ (6096 mm) depending on gauge and slat type
Curtain Material:
- Galvanized steel interlocking roll-formed slats and end locks are attached to prevent lateral movement.
- C-187 for doors up to 15’4″ wide – 22 gauge;
- Curved profile type C-275 for doors from 15’5″ to 18’4″ wide – 22 gauge; From 18’5″ to 25’4″ – 20 gauge; From 25’5″ to 30’0″ – 18 gauge
EverServe® Model 620s
Max Width: up to 30′ (9246 mm) depending on gauge and slat type
Max Height: up to 20′ (6096 mm) depending on gauge and slat type
Curtain Material:
- Galvanized steel interlocking roll-formed slats and end locks are attached to prevent lateral movement.
- Flat Profile type F-265 for doors up to 18’4″ wide – 22 gauge; From 18’5″ to 25’4″ – 20 gauge; From 25’5″ to 30’0″ – 18 gauge
EverServe® Model 625s
Max Width: up to 30′ (9246 mm) depending on gauge and slat type
Max Height: up to 20′ (6096 mm) depending on gauge and slat type
Curtain Material:
- Galvanized steel interlocking roll-formed slats and end locks are attached to prevent lateral movement.
- Insulated flat profile (F-265i) for doors up to 30′ wide – front and back slats 24 gauge. The slat cavity shall be filled with CFC-free, foamed-in-place, polyurethane insulation.
Insulation
- R-value* of 7.71 for energy-efficiency.
- U-value of .13 and STC rating of 21
Mounting: Interior or exterior face of wall
Control panel: Electronic controller with microprocessor self-diagnostics. Digital readout indicates door action, alarm conditions, and fault conditions. Time delay self-close timer and non-resettable cycle counter is included. One open/close/stop push button station integrated in control panel. Enclosure is IP54 rated (NEMA 3 equivalent).
Curtain Finish: Gray, tan or white PowderGuard® Max powder coat with hardening additive
Bottom bar: Two PowderGuard® Premium powder coated black angles (min. thickness 3/16”) with 2-wire, self-monitoring, fail safe, electric sensing edge
Hood: 24 gauge galvanized steel primed, black painted; interior hood baffle included
Brackets: Min. ¼” hot rolled primed, PowderGuard® Premium powder coated black steel
Guides: Three structural steel angles PowderGuard® Premium powder coated black
Door roll: Direct driven, springless roll with integrated shafts; self-aligning grease-able sealed bearings; door does not require counterbalance device
Stormtite™ perimeter seal system Exterior guide seal, interior hood baffle, bottom astragal
Safety devices:
- Built-in brake mechanism provides additional peace-of-mind against uncontrolled curtain travel
- Wireless monitored safety edge – all doors are equipped with a mandatory reversing or sensing edge to prevent entrapment.
- Photoelectric safety sensors with guards – provide additional safety during door operation to help prevent injury and damage
Operation:
Direct drive, integrated gear motor/brake assembly (up to 24” per sec up speed / 12” per sec down speed); drive assembly and limit sensors are factory pre-assembled. Manual hand chain for power outage. Horsepower is appropriate to size and weight of door. 230V AC 3-phase motor
Actuator: Single open/close/stop push button station incorporated into control panel
Wind load: 20 psf when optional wear strips are not specified
Warranty
5 year limited warranty coverage on all mechanical door system components and control panel hardware.
- Motor options: 208V AC 1PH†, 220V AC 1PH, 208V AC 3PH†, 230V AC 3PH, 460V AC 3PH†, 575V AC 3PH†
(†requires stand-alone mounted transformer) - Flat profile type F-265 for doors up to 30’ wide. Available in: 20, 18 gauge galvanized steel; 22, 20 gauge stainless steel; 16 gauge (.050”) aluminum*
- Bottom bar also available in: galvanized steel, stainless steel and aluminum
- Guide options include galvanized steel, powder coated steel
- Hood available in powder coat, stainless steel and aluminum; sloped hood also available
- Brackets also available in powder coat, galvanized steel
- IP65 (NEMA 4/4X equivalent) control panel
- Sensing edge for improved safety
- Additional set of photoelectric sensors
- Optional push buttons, loop detectors, radio control, motion detectors or any combination thereof available for door operation/control
- PowderGuard® Premium powder coat and PowderGuard® Max hardened powder coat available in approximately 200 colors as well as colormatching to specification
- PowderGuard® Textured Finish: Industrial textured powder coat provides a thicker, more scratch resistant coat for added product protection on guides, bottom bar and head plate
- Uniformly spaced glazed acrylic vision lites available in 3” x 5/8” or 10” x 1”
- High wind load options available
*Consult factory for specific slat profile and gauge width limits.
Exterior Color Options
Model 592 Colors
White Tan Gray Brown
Powder Coat Color Options
PowderGuard® Premium powder coat options are available in approximately 200 colors and custom matching to specification.
