Thermacore® Sectional Steel Doors 593/594
Superior Performance & Built To Last
Thermacore® is the premier line of insulated sectional doors available today. Thermacore® Sectional Steel Doors 593/594 are designated for applications when your project requires a thermal door that is as energy efficient as it is attractive.
Strong, Lightweight, Attractive and Durable
Long-Lasting Performance for a Broad Range of Applications
Thermacore® Sectional Steel Doors 593/594 are fabricated using Overhead Door’s proprietary, computer-controlled manufacturing process. The result is an exceptionally well-built door that adheres to the strictest product tolerances and quality standards – for long-lasting performance and good looks.
Ideal Applications Include
Warehouse Solutions
Manufacturing
Automotive
Service Stations
Government Facilities
Thermacore® Sectional Steel Doors 593/594 Overview
The Thermacore® Sectional Door Model 593 is one of the best-selling doors in the Thermacore® line. Its exterior skin is galvanized steel with a ribbed, textured finish.
The Thermacore® Sectional Door Model 594 offers excellent thermal efficiency for medium-duty applications. These doors feature a raised-panel, wood-grain textured surface for a more decorative appearance. This product is an exceptionally popular choice for RV door applications.
..
Thermacore Model 593, Custom Color, Ribbed Panel, Windows: Aluminum Sash Section with DSB Glazing
Thermal efficiency
U-factor* .15
R-value**: 12.76 (K m2/W)
thermal break:Hot melt
Air infiltration: at 15 mph (24 kmph) .08 cfm/ft2 (1.46 m3/hr/m2)
*U-factor values are independently tested and verified per ANSI/DASMA 105.
**Overhead Door uses a calculated door section R-value for our insulated doors.
Max width: 20’2”
Max height: 16’1″
Section Thickness: 1 3/8″ (35 mm)
Material: Steel
Model 593 Material Gauge: .015″ (.38 mm) galv
Model 594 Material Gauge: .012″ (.3 mm) galv.
Exterior Surface Ribbed, or Raised textured Panel
Standard Springs 10,000 cycles
Warranty
- 10 year limited delamination
- 1 year limited on door
- 3 year/20,000 cycle limited on door & operator system (when purchased together; on material and workmanship)
- 20 year limited on high performance fluoropolymer coating option
- Chain Hoist or Electric Operator is recommended for doors above 10’ tall or more than 400 pounds
- Aluminum sash section available up to 24’2″ (7,366 mm) wide
- Insulated glass, tempered glass, polycarbonate, multi-wall polycarbonate, etc.
- High performance fluoropolymer coating (Trinar® or equivalent)
- Four-section pass door
- High-usage package
- Wind load options
- Electric operator
- Chain hoist
- Posi-Tension™ drums
- Safety bottom fixture
- Bottom-sensing edge
- Flexible jamb, header seal
- Exhaust ports
- Window Glazing Options
- Impact Section Available
Ribbed, Textured Panel Raised textured Panel
Colors – Both Models
White Tan Gray Industrial Brown
Trinar White Trinar Brown Trinar Beige
Colors – Model 594
Desert Tan Hunter Green Terra Bronze
High performance fluoropolymer coating (Trinar® or equivalent) finish option available in white, brown, and beige. Offers superior performance.
Actual colors may vary from brochure due to fluctuations in the printing process. Always request a color sample from us for accurate color matching.
Glazing Options
Model 593
Double Thermal Acrylic (25” w by 12” h)
Aluminum Sash Section* with DSB glazing
Insulated DSB (24” w by 7” h)
Clear Long* (44” w by 15” h)
*Not available on doors wider than 20’2”.
Model 594
Insulated DSB (20.75”w by 15”h
Aluminum Sash Section* with DSB glazing
